| Model | HT-800 |
| Dimension(L*W*H) | 850*1280*1500mm |
| Control method | Controler + IPC |
| (XYZ)Dispensing area | X=400mm Y=400mm Z=40mm |
| Drive method | Servo motor+Ball screw |
| Max running speed | 1500mm/s |
| Positioning accuracy | ±0.02mm |
| Repeat positioning accuracy | ±0.02mm |
| Nozzle matched | 1set(It is equipped with double standard valve,and can be equipped with doublevalve.) |
| Nozzle heating | Ambient Temperature-~100℃ |
| Communication port | SMEMA interface |
| Scanner port | 232 port |
| Programming mode | Offline or online visual programming |
| Power supply | AC220V 50～60HZ |
| Air supply | 0.6MPa |
| Total power | 2.4KW |
| Weight | 950kg |
